| Property | Description |
|---|---|
| User Interface | 15.1 inch Color touch Screen with USB Drive |
| Design File Format | .SAS, .DAT |
| Main Shaft Control | A C Servo Motor |
| Frame Motion Control | X, Y1, Y2 Axis AC Servo Motors. |
| Borer Control | A C Servo Motor. |
| Fabric Feeding | Roll Form ( up to 150 Mtrs x One Frame) |
| Fabric Width | 120 inches to 150 inches. |
| Automatic Thread Feeding | A C Servo Motor. |
| Operating Voltage | 220V; 3 Phase. |
| Rated Power | 3.2 Kw |
| Maximum Speed (rpm) | 400 RPM |
| Horizontal Frame Movement | 500 mm |
| Vertical Frame Movement | Continues… |
| Minimum Stitch Length | 0.16 mm ( X and Y ) |
| Maximum Stitch Length | 16.5mm ( X and Y ) |
| Maximum Borer Depth | 20 mm |
| Shuttle Size | #10 ( Left Hand Side) |
| Number of Needles | 143 Nos |
| Machine Length | 6260 mm |
| Machine Width | 1420 mm |
| Machine Height | 2360 mm |
| Machine Weight | 5.2 Ton |
| Frame | Single Width |
| Repeat | as schiffli 4/4, 8/4, 12/4…. |
| Foundation | Not required |
